水声材料低频声性能的行波管测量

Traveling wave tube measurements for low-frequency properties of underwater acoustic materials

  • 摘要: 发展了一种测量水声材料声学性能的行波管测量技术,能够在实验室充水管中模拟海洋水温水压环境,对样品的声学参数实施低频范围的测量。被测样品置于声管中央,声管两端配置一对发射器。应用主动消声技术使样品的透射声波在声管次发射器表面的反射可忽略,在管中建立起行波声场。然后,通过分别计算样品两边声场中每一对水听器的传递函数,得到样品的反射系数和透射系数。测量系统声管的内径为Φ208 mm,工作频率范围为100~4000 Hz,最高静水压为5 MPa。对水层和层状不锈钢样品的反射系数和透射系数进行了实际测量和理论计算,结果表明,测量值和计算值有较好的吻合,测量不确定度不大于1.5 dB。



    Abstract: A traveling wave tube measurement technique is developed for measuring acoustic properties of underwater acoustic materials. In the laboratoryr water temperature and pressure environments of the ocean can be simulated in the water-filled tuber and the acoustic parameters of samples are measured in range of low frequencies. A tested sample is located at central position of the tube. A pair of projector is separately located at both ends of the tube. Using active cancellation technique, transmitted sound wave of the sample is hardly reflected by the surface of secondary transducer. So the traveling sound field is built up in the tube. By separately calculating the transfer functions of every pair of hydrophone in the both sound fields separated by the sample, its reflection coefficients and transmission coefficients are obtained. In the measurement system, the inside diameter of the tube is Ф208 mm, the working frequency range is 100 N4000 Hz, the maximum pressure is 5 MPa. The reflection coefficients and transmission coefficients of water layer and stainless steel layer samples are measured actually and calculated theoretically. The results show that the measured values are in good agreement with the calculated, and the measurement uncertainty is not greater than 1.5 dB.



/
